ASAB S Series - Replacement S1/S3 Ball Cage

The ASAB S1/S3 Ball Cage is a critical check-valve component that keeps the check ball correctly located and guided during pump operation. It helps the valve seat cleanly on every stroke, which is essential for steady prime, consistent pressure, and smooth material flow.

If a sprayer is slow to prime, pulses, won’t hold pressure, or backflows through the pump, a worn, damaged, or contaminated ball cage is one of the usual suspects. Replacing it restores proper check action and helps protect the pump from unnecessary wear—because a check valve that can’t “check” is just a leak with confidence.

Key features

• Maintains correct check ball alignment and travel for reliable sealing

• Supports consistent pressure and improved priming performance

• Ideal replacement when the existing cage is scored, cracked, worn, or difficult to clean back to spec

• Compatible with ASAB S1 / S3 pump check-valve assemblies (model-dependent)

What’s included

• 1 x Ball Cage (service replacement)

Safety Check

• Relieve all fluid pressure before loosening any pump components (follow the sprayer’s pressure relief procedure).

• Isolate power (unplug/disconnect) before servicing the fluid section.

• Wear PPE: eye protection and chemical-resistant gloves—paint and solvents don’t negotiate.

• Injection hazard: never check for leaks with your hand; high-pressure fluid can penetrate skin.

• Test carefully after reassembly: prime at low pressure first, confirm sealing/no leaks, then return to normal operation.
